| CPU | ARM Cortex |
| Display | 4x20 Backlit LCD Display |
| View area: 70MIN(W) X 40MIN(H) | |
| Keypad | Type: DOM Switch |
| No of Keys: 9 | |
| Printer | Type: 2 inch Thermal |
| Speed: 80mm/sec | |
| Resolution: 8 dots/mm of resolution | |
| GPS | Receiver Band Frequency: 1575.42MHz |
| Channel Number: 22 (tracking) / 66 (acquisition) | |
| Horizontal Position Accuracy: Autonomous <2.5m CEP | |
| TTFF with AGPS: Cold Start <15s Warm Start <5s Hot Start <1s TTFF without AGPS: Cold Start <35s Warm Start <30s Hot Start <1s | |
| Protocols: NMEA 0183, PMTK | |
| Antenna: Internal Active Patch Antenna | |
| GPRS | Quad-band: 850/900/1800/1900 MHz |
| DATA: GPRS Class 12 Max. 85.6 kbps (uplink & downlink) | |
| Protocols: PPP/TCP/UDP/HTTP/FTP/SMTP/MUX | |
| Voice: 2 Way Communication option | |
| Sensor | Proprietory Protocol with tamper detection |
| Internal Battery | Type: Lithium Ion |
| Capacity: 1250mAH | |
| Backup Time: 6 Hours | |
| RTC Battery | Lithium Ion Coin Cell |
| Power Supply & Circuit Protection | Vmin = 5V, Vmax = 36V Protection: TVS Diodes, PTC, Voltage Suppressors |
